Designed for solar power plants and utility grid connection, this 0.69kV to 33kV oil immersed step-up transformer delivers stable voltage boosting performance for photovoltaic energy systems. It efficiently converts low-voltage output from solar inverters into medium-voltage power for long-distance transmission and grid integration.
The Solar Step-Up Transformer is specially designed for photovoltaic power generation systems and utility-scale solar farms. It converts the low-voltage output power generated by solar inverters (0.69kV) into medium-voltage power (33kV) for efficient long-distance transmission and stable grid connection.
This oil immersed power transformer adopts high-quality silicon steel cores and premium copper windings to ensure low loss, high efficiency, and long-term operational reliability. It is suitable for harsh outdoor environments and continuous operation in renewable energy projects.
Widely used in solar power stations, containerized substations, renewable energy systems, and utility grid integration projects.
Zisheng are a professional 19+ years manufacturer in producing Oil-Immersed Transformers, Compact Substation, Pad Mounted Transformers, Pole Mounted Transformers and Dry Type Transformers. We own the certificates of ISO/CE/IEC 60076 and TUV Rheinland.
Transformers undergo rigorous FAT and type testing, support voltage/capacity customization. Welcome to consult for Catalog and Product. you can contact us at email [email protected].
Product Features
High Energy Efficiency
Adopts low-loss CRGO silicon steel core design to reduce no-load and load losses, improving overall energy conversion efficiency.
Stable Grid Connection
Designed specifically for photovoltaic systems with stable voltage boosting performance and excellent harmonic resistance.
Strong Outdoor Adaptability
The sealed oil tank structure provides excellent moisture-proof, dust-proof, and corrosion-resistant performance for outdoor solar farm environments.
Reliable Cooling System
Efficient ONAN/ONAF cooling ensures stable operation under high temperature and continuous full-load conditions.
Custom Engineering Support
Supports customized voltage, capacity, frequency, and installation solutions according to project requirements.
| Item | Specification |
|---|---|
| Product Type | Oil Immersed Step-Up Transformer |
| Application | Solar PV Power Plant |
| Rated Capacity | 2500kVA |
| Rated Power Frequency | 50Hz / 60Hz |
| LV Voltage | 0.69kV |
| HV Voltage | 33kV |
| Vector Group | Dyn11 / Yd11 |
| Cooling Method | ONAN / ONAF |
| Insulation Class | Class A |
| Impedance Voltage | 6%–8% |
| Tap Changer | Off-circuit / On-load Optional |
| Winding Material | Copper / Aluminum Optional |
| Core Material | CRGO Silicon Steel |
| Temperature Rise | 55K / 65K |
| Protection Level | IP54 (Optional) |
| Standards | IEC / ANSI / IEEE |
| Installation | Outdoor |
| Service Life | ≥25 Years |
Utility Scale Solar Farms
PV Power Stations
Renewable Energy Projects
Containerized Substations
Industrial Solar Systems
Grid Connection Systems
Optional Configurations
OLTC / NLTC Tap Changer
Remote Monitoring System
Temperature Controller
Buchholz Relay
Pressure Relief Device
Anti-corrosion Coating
Customized HV/LV Voltage
Factory Advantages
Advanced Automatic Production Line
Professional Transformer Testing Laboratory
Strict Quality Control System
OEM & ODM Support
Fast Delivery for Overseas Projects
Export Experience in Asia, Africa, Middle East & South America
Reliable Solar Power Transformation Solution
Efficient. Stable. Durable.
Customized transformer solutions for global photovoltaic power projects.
