The 100kVA dry-type transformer adopts efficient dry-type insulation technology and is designed for industrial, commercial and residential power systems. With its excellent performance and compact structure, the transformer provides stable and reliable power support and is suitable for small and medium-sized power distribution needs. Through strict quality control, NPC ELECTRIC's 100kVA dry-type transformer provides users with high-quality, low-maintenance power solutions.
The 100kVA Dry Type Transformer is a high-performance, safe, and environmentally friendly distribution transformer designed for medium and low voltage power distribution applications. It is widely used in commercial buildings, industrial facilities, renewable energy systems, data centers, hospitals, and infrastructure projects where safety, reliability, and low maintenance operation are essential.
Unlike traditional oil immersed transformers, the 100kVA dry type transformer adopts an epoxy resin cast insulation system, eliminating the need for transformer oil and significantly reducing fire risks and environmental concerns. This makes it an ideal choice for indoor substations, high-rise buildings, underground facilities, and locations with strict safety requirements.
The transformer is manufactured with a high-quality grain-oriented silicon steel core and optimized magnetic circuit design. The advanced core structure effectively reduces no-load losses, improves energy efficiency, minimizes operating noise, and ensures stable performance during continuous operation.
The winding system adopts high-quality copper or aluminum conductors with advanced casting technology. The epoxy resin encapsulated winding provides excellent insulation strength, high mechanical stability, and strong resistance to moisture, dust, and temperature fluctuations. This design improves short-circuit resistance and ensures reliable operation under different load conditions.
The 100kVA dry type transformer uses an efficient air cooling system (AN/AF) to maintain proper operating temperature. Its compact structure, excellent heat dissipation performance, and flexible installation design allow it to operate reliably in various indoor environments with limited space.
During manufacturing, every transformer undergoes strict quality control from raw material inspection, core assembly, winding production, resin casting, assembly, and final testing. Before shipment, each unit is tested according to international requirements, including insulation resistance testing, winding resistance testing, voltage ratio testing, no-load loss testing, load loss testing, dielectric strength testing, and temperature rise testing.
With its outstanding safety performance, energy efficiency, and long service life, the 100kVA Dry Type Transformer provides a reliable power distribution solution for modern electrical systems.
Zisheng are a professional 19+ years manufacturer in producing Oil-Immersed Transformers, Compact Substation, Pad Mounted Transformers, Pole Mounted Transformers and Dry Type Transformers. We own the certificates of ISO/CE/IEC 60076 and TUV Rheinland.
Transformers undergo rigorous FAT and type testing, support voltage/capacity customization. Welcome to consult for Catalog and Product. you can contact us at email [email protected].
A hospital project required a safe, reliable, and low-maintenance power distribution solution to support critical loads, including medical equipment, lighting systems, HVAC systems, and emergency power facilities.
Due to strict fire safety requirements and indoor installation conditions, the customer selected a 100kVA Dry Type Transformer for the building’s power distribution system.
The transformer adopted epoxy resin cast insulation technology, low-loss silicon steel core, and advanced cooling design, providing stable voltage output, excellent insulation performance, and reliable operation under continuous load conditions.
After installation, the transformer successfully improved the stability of the hospital’s electrical system and provided a safe and efficient power supply solution for long-term operation.
Project Type: Hospital Power Distribution System
Product: 100kVA Dry Type Transformer
Application: Indoor Substation
Voltage: 11kV/0.4kV (Customized)
Standard: IEC 60076
| Rated Power | 100 kVA | |
| Rating Primary Voltage | 2.4-34.5kV | |
| Secondary Voltage | 480/277V 400/230V 380/220V Customized | |
| Frequency | 50/60Hz | |
| Vector Group | Dyn11,Yyn0,Dyn5 | |
| Winding Material | Aluminum/Copper | |
| Efficiency | As IEEE,Doe 2016,CAS Std or Customized | |
| Impedance Voltage | Nominal 2% or Customized 1.1-5.75% | |
| Altitude | ≤1,000m or Customized | |
| Enclosure material | 304 Stainless Steel | |
| Total Weight | 500 kg | |
| Outline Dimensions（L×W×H）in. | 850×650×1150（mm) | |
| HV Bushing |
| LV Bushing |
| Tap changer connector |
| Lifting hook for complete transformer |
| Name plate |
The 100kVA Dry Type Transformer is mainly used for indoor power distribution in commercial buildings, industrial plants, hospitals, data centers, renewable energy projects, and infrastructure facilities.
Dry type transformers use epoxy resin insulation instead of transformer oil, offering high fire safety, no oil leakage risk, low maintenance requirements, and excellent environmental adaptability.
The voltage ratio can be customized according to project requirements, such as 10kV/0.4kV, 11kV/0.4kV, 13.8kV/0.48kV, or other voltage levels.
Yes. Its oil-free design makes it especially suitable for indoor substations, high-rise buildings, hospitals, shopping malls, and other locations with strict safety requirements.
The standard cooling method is AN (Air Natural Cooling). Optional AF (Air Forced Cooling) can be provided for higher capacity requirements or special applications.
Yes. The epoxy resin cast insulation provides excellent resistance to moisture, dust, and temperature variations. Additional protection can be customized for harsh environments.
Each transformer undergoes complete factory testing, including:
Yes. We provide customized solutions including voltage ratio, frequency, winding material, protection class, enclosure design, and accessories according to customer requirements.
With proper installation and maintenance, the transformer can provide reliable operation for 20–30 years or more.
The transformer is designed and manufactured according to international standards such as IEC 60076, ensuring safety, reliability, and stable performance.
