The 5kVA Conventional Type Single Phase Pole Mounted Transformer is designed for overhead distribution systems, providing reliable, energy-efficient power for rural electrification, residential areas, farms, and utility networks.
The 5kVA Conventional Type Single Phase Pole Mounted Transformer is a compact oil-immersed distribution transformer designed for overhead distribution systems. It is widely used in rural electrification, residential distribution, agricultural power supply, street lighting, and utility networks. Installed directly on utility poles, it offers a cost-effective and reliable solution for low-capacity power distribution.
Designed and manufactured in accordance with IEC 60076, ANSI/IEEE C57, and other international standards, this transformer features high efficiency, low losses, and long-term operational reliability in demanding outdoor environments.
Zisheng are a professional 19+ years manufacturer in producing Oil-Immersed Transformers, Compact Substation, Pad Mounted Transformers, Pole Mounted Transformers and Dry Type Transformers. We own the certificates of ISO/CE/IEC 60076 and TUV Rheinland.
Transformers undergo rigorous FAT and type testing, support voltage/capacity customization. Welcome to consult for Catalog and Product. you can contact us at email [email protected].
Product: 5kVA Conventional Type Single Phase Pole Mounted Transformer
Location: Kenya
Application: Rural Electrification Project
A total of 86 units of 5kVA Conventional Type Single Phase Pole Mounted Transformers were supplied for a rural electrification project in western Kenya. The transformers were installed on overhead distribution lines to provide stable electricity to villages, schools, healthcare centers, and small farms where access to reliable power had previously been limited.
Designed for outdoor operation, each transformer features a sealed oil-immersed tank, low-loss CRGO silicon steel core, and corrosion-resistant coating, ensuring dependable performance in tropical environments.
| Rated Power | 5 kVA |
| Rating Primary Voltage | 12.4-34.5kV |
| Secondary Voltage | 480-240V 240-120V 277V Customized |
| Frequency | 50/60Hz |
| Vector Group | Ii0,Ii6 |
| Winding Material | Aluminum/Copper |
| Efficiency | As IEEE,Doe 2016,CAS Std or Customized |
| Impedance Voltage | Nominal 2% or Customized 1.1-5.75% |
| Altitude | ≤1,000m or Customized |
| Color | ANSI 70 Light gray/Munsell 7GY3.29/1.5 or customized etc |
| Tank material | Mild Steel, 304 Stainless Steel |
| Insulating Oil Weight | 15 kg |
| Total Weight | 92 kg |
| Outline Dimensions（W×D×H） | 465×485×855 (mm) |
| Lifting Lug |
| Tap Changer |
| Pressure Relief Valve |
| Tank Cover and clamp |
| L.V Bushing |
| HV Bushing |
| Ground Strap |
| Nameplate |
| Non-PCB decal |
| High Voltage Warning Signs |
| Suport lug |
| Oil fill valve |
It is a small-capacity oil-immersed transformer installed on utility poles for overhead distribution networks. It provides reliable voltage transformation for residential, agricultural, and rural power supply.
Typical configurations include:
Yes. We offer customized solutions including voltage ratings, frequency, copper or aluminum windings, insulating oil type, paint color, and customer nameplate.
The transformer can be manufactured according to:
This transformer is widely used in rural electrification, utility distribution systems, farms, villages, residential areas, street lighting, and small industrial facilities.
Yes. Every unit undergoes comprehensive routine testing before shipment, and a complete factory test report is provided.
Under normal operating conditions and proper maintenance, the expected service life is 25–30 years.
Yes. We export worldwide and provide export packaging, shipping documents, and technical support for utilities, EPC contractors, distributors, and power projects.
